Linear
Positioners
ANPz51eXT | closed loop
linear, vertical, and compact stepper positioner with extended travel range and position encoder
ANPz51eXT | RES - positioner with resistive encoder
200 nm
10 mK .. 373 K
0 .. 31 T
Size and Dimensions
footprint; height
15 x 18; 17 mm
maximum size
15 x 18; 23 mm
weight
15 g
Accuracy of Positioning
encoder type
resistive sensor
sensor resolution
approx. 200 nm
repeatability
approx. 1 .. 2 µm
Compatibility with Electronics
closed loop controller
ANC350/RES
for all other specifications see open loop model ANPz51eXT
