attoAFM/MFM I+
PAGE 31
Included features
attoAFM I+ head
• 125 μm scan range @ 4 K
• closed loop scanning @ 1 nm resolution
...for further details, see page 27
• alignment-free cantilever holder
• tip exchange in less than 2 minutes
...for further details, see next page
PRODUCT KEY FEATURES
• interferometric encoders for closed loop scanning
with 1 nm resolution
• 125 μm scan range @ 4 K
• attoAFM I+ head feat. alignement-free cantilever holder
• quick exchange sample holder with 8 electrical contacts
• ultra compact, highly rigid MFM head
• highly sensitive interferometric deflection detection
• adjustment of the cantilever outside the cryostat prior
to cooling the microscope
Kelvin Probe
Force Microscopy
BENEFITS
• easy tracking of regions of interest & distortion-free images
• tip exchange in less than 2 minutes
• high spatial resolution imaging
• simultaneous ultra high resolution topographic &
magnetic force imaging
• compatible with any commercially available MFM probe
Piezo-Response Force
Microscopy
APPLICATION EXAMPLES
• investigation of superconductors
• domain structure studies
• materials science
Conductivity Mapping
COMPATIBLE COOLING SYSTEMS
• attoLIQUID1000/2000/3000, attoLIQUID5000 (on request)
• attoDRY1000/1100/2100
The attoMFM I+
microscope module
