ASC500
fully digital SPM controller with xy-scan generator and z feedback control, phase-locked loop (PLL)
The ASC500 is a modular and flexible digital SPM controller which combines state-of-the-art hardware with innovative software architecture,
offering superior performance and unprecedented variety of control
concepts. It was developed with the goal to never be the limiting factor
in any scanning probe microscopy (SPM) experiment.
All desirable functions and high-end specifications for conducting
the experiment of your choice in AFM, MFM, KPFM, PRFM, CFM, SHPM,
SNOM, STM, and many more measurement techniques are available. The
ASC500 features optional closed loop functionality, fully supporting
attocube’s FPS interferometric sensors.
Digital I/O:
Analog inputs:
Analog outputs:
Scan outputs:
High frequency section:
Auxiliary
power:
8 inputs
8 outputs
40 MHz
6 converters
400 kHz
18 bit
4 converters
200 kHz
16 bit
2 analog modulation
inputs
3 converters
4 MHz in xy;
highest
resolution,
z modulation
input
2 independent HF channels
with each:
50 MHz, 16 bit input
50 MHz, 16 bit output
Sync output
Preamplified signal monitor
±5 V
±15 V
