attoSENSORICS – Accessories
PAGE 222
Accessories.
optional items for the attoSENSORICS product line
Vacuum Fiber Feedthrough
KF flange: We supply KF vacuum flanges with FC/APC optical feedthrough in sizes KF16 to KF63, with
one to three optical feedthroughs (depending on flange size). KF flanges are vacuum compatible
down to 10 -8 mbar (high vacuum).
KF40/3
CF flange: We supply CF vacuum flanges with FC/APC optical feedthrough in sizes CF16 to CF63, with
one to three optical feedthroughs (depending on flange size). CF flanges are compatible down to
5x10 -11 mbar and can be baked out at up to 180 °C. These CF flange feedthroughs are designed for UHV
operation.
Article
FPS
IDS
KF40/1:
1007201
1010714
KF40/3:
1007203
1010715
CF40/1:
1007192
1010716
CF40/3:
1007196
1010717
CF40/3
Cables / Wiring Options
2.5 m
BNC 1m
HDMI to SubD adapter cable incl. level adaptation: connecting from HDMI to SubD, supplying both
differential AquadB, single-ended AquadB, and single-ended HSSL outputs. One adapter cable is
required per axis. Compatible with both FPS1010 and FPS3010, output level complies with TTL/LVDS
standards. In addition, we supply a SubD to BNC cable with a length of 1 m to get a direct connection
to the single-ended AquadB signal via BNC connetors.
Article
Art. No.
2.5 m:
1007329
10 m:
1007332
BNC 1 m:
1007330
