attoSENSORICS – Accessories
PAGE 220
Accessories X
optional items for the attoSENSORICS product line
Angular measurement software upgrade
With the angular measurement software, the FPS can now also be used
to non-invasively measure angular position variations with high resolution. The software is set up to handle three sensor heads in parallel,
displaying two angular and one linear position information. As with the
linear measurement software, the angular software outputs position
information via USB, AquadB, and HSSL.
Specific sensor head holders for angular measurements are available.
Technical specifications
number of axes
three - alpha, beta, linear
max. sensor separation
d ≤ 3000 mm
bandwidth
10 MHz (angular & linear)
position output
US
