Accessories
attoSENSORICS – Accessories
PAGE 218
Accessories.
optional items for the attoSENSORICS product line
Accurate interferometrical measurements in ambient environment
In order to reduce position inaccuracy due to air-induced variations of the index refraction, attocube
supplies an environmental compensation unit (ECU). By locally measuring environmental parameters, an accuracy of typically better ± 1 ppm can be achieved in air. The ECU is plug and-play compatible with all IDS models and can be screw- or magnet mounted.
Technical Specifications
art. no.
IDS ECU
dimensions
weight
FPS
IDS
1008536
1010698
Ø 37 mm, height: 17.4 mm
28 x 61 x 20.5 mm³
36.5 g
41.5 g
integrated sensors
interface
sensor mount
T, p, rH
GPIO port
working environment
cable lenght
RJ12 connector
magnetic mount, screw mount
5m
3m
Measurement Accuracy (Sensors)
FPS ECU
screw mount
non condensing
T-sensor
±0.1°C (0..50°C)
p-sensor
±1 hPa (300..1100 mbar)
rH-sensor
±2% (10..90%)
typ. accuracy setup
better ± 1 ppm
