FPS Sensor
Systems
PAGE 197
1
Synchronous Data Visualization
4 High-Speed FFT Analysis
The new FPS software allows the user to choose a common time
base for all three axes in order to display displacement data
synchronously. This feature makes visualizing crosstalks or interferences between measurement axes a simple task.
If desired, the user can switch back to individual time bases
for each axis at any time.
2 Synchronous Data Storage
In addition to choosing a common time base for visualization
purposes, the FPS system allows synchronous data storage.
Position data of all three axes will be saved into one common
file with a word length of 64bits for each axis, making data
evaluation as simple as never before.
3
Dynamic Link Libraries & Virtual Instruments
With the included DLL and LabVIEW VI’s, all features of the PC
software can be accessed through C/C++/C# and LabVIEW,
including tracking of alignment signal during a running
measurement task. In addition, all general settings &
parameters can be adjusted.
The FPS sensor software provides frequency analysis of
displacement data at frequencies up to 5 MHz. This powerful
tool makes measurement of resonance modes and according
quality factors an easy operation.
5
Data Marking
With the data marking feature, stored data can be correlated
with or marked by external trigger events. This optional feature
enables the user to correlate displacement information to
external sources or events, greatly facilitating data evaluation.
6 Improved Initialization Routine
The new software includes push-button reinitialization of system parameters during ongoing measurements, significantly
increasing alignment tolerances of sensor heads. The smart
alignment feature further prevents misalignment errors (e.g.
Abbé error) and improves signal-to noise ratio by presetting
maximum target speeds.
attoSENSORICS
Ultra Precision Sensors
